LG 2.0HP Dual Inverter WiFi Air Conditioner (HS-18ISY)

Sale price₱50,700.00

Or 3 months for only ₱1,000 with . Learn More.
*The actual product image may differ from the image shown above.

Dual Inverter Compressor™1

Dual Inverter Compressor™


10 Year Warranty110 Year Warranty
Sleep Mode1

Sleep Mode

Sleep Mode will increase the temperature by a degree every 30 minutes, and eventually by 2 degrees per hour to create a more comfortable and sound sleeping atmosphere.

Gold Fin™1Gold Fin™

The Gold Fin™ ensures that the surface is more resistant to corrosion and enhances the durability of heat exchanger for a much longer period.

DIMENSIONS

HSN18ISS

SUMMARY

  • CAPACITY
    2HP
  • DIMENSIONS NET W X H X D (MM) INDOOR / OUTDOOR
    998 x 345 x 210
    770 x 545 x 288
  • MAIN TECHNOLOGY
    Dual Inverter
  • ADDITIONAL BENEFIT
    Active Energy Control



CAPACITY
  • Cooling (Min ~ Rated ~ Max)
    5.28 kW
    18,000 Btu/h
    18,990 kJ/h
    Capacity
    2.0HP
POWER INPUT
  • Cooling (Min ~ Rated ~ Max)
    1,540 W
RUNNING CURRENT
  • Cooling (Min ~ Rated ~ Max)
    7.10 A
EER
  • EER
    3.43 W/W
    11.69 (Btu/h)/W
    12.33 (kJ/h)/W
POWER SUPPLY
  • Power Supply
    1, 230, 60 (Ø, V, Hz)
    Available Voltage Range
    187 ~ 276 V
  • Power Factor - Cooling
    94%
    Moisture Removal
    1.25 l/h
    2.64 pts/h
  • Circuit Breaker
    25 A
    Power Supply Cable
    3 × 1.5 No. × mm²
  • Power Supply to Unit
    Indoor
    Power and Communication Cable
    4 × 1.5 No. × mm²
INDOOR UNIT
  • Air Flow Rate - Cooling, Max/H/M/L
    18/12.7/10.2/8.4 m³/min
    635.7/448.5/360.2/296.6 CFM
    Fan Motor Speed - Cooling, Max/H/HM/M/ML/L/SL
    1500/1150/1050/950/860/770/700 rpm
  • Sound Pressure Level - Cooling, Max/H/M/L/SL
    -/45/40/37/32 dB(A)
    Dimensions (W × H × D) - Net
    998 x 345 x 210 mm
  • Dimensions (W × H × D) - Shipping
    1068 x 425 x 279 mm
    Weight - Net
    11.2kg
  • Weight - Shipping
    13.2kg
    Disconnect Switch
    25 A
  • Exterior Color Code
    Munsell 7.5BG 10/2 (RAL 9016)
    Operation Range - Cooling
    16 ~ 32 °C DB
    61 ~ 90 °F DB
    10 ~ 23 °C WB
    50 ~ 73.4 °F WB
OUTDOOR UNIT
  • Air Flow Rate - Max
    31.0 m³/min
    1095 CFM
    Sound Pressure Level - Cooling, Rated
    53 dB(A)
  • Dimensions (W × H × D) - Net
    770 x 545 x 288 mm
    Dimensions (W × H × D) - Shipping
    920 x 588 x 393 mm
  • Weight - Net
    32.5kg
    Weight - Shipping
    34.8kg
  • Max. Fuse Size
    15 A
    Exterior Color Code
    Munsell 9.54Y 8.34/1.31 (RAL 9001)
  • Operation Range - Cooling
    18 ~ 48 °C DB
PIPING
  • Size - Liquid
    ø 6.35 mm
    Size - Gas
    ø 12.7 mm
  • Connections Method - Indoor/Outdoor
    Flared/Flared
    Drain Hose Size - O.D, I.D
    21.5, 16.0 mm
  • Max Piping Length Capacity
    98.7%
BETWEEN INDOOR & OUTDOOR
  • Piping Length - Min/Standard/Max
    3/7.5/30 m
    Piping Length - No Charge
    12.5 m
  • Max. Elevation Difference
    20m
    Piping Connection Heat Insulation
    Both liquid and gas pipes
REFRIGERANT
  • Type
    R32
    Pre Charge
    950g
  • Additional Charge
    15g/m
    Control
    Capillary
  • Global Warning Potential
    675
    t-CO₂ eq
    0.641
TOOL CODE(CHASSIS)
  • Indoor / Outdoor
    SK / UL2
COMPRESSOR
  • Type
    Twin Rotary
    Model
    DAT156MAD
  • Motor Type
    BLDC
    Oil Type / Maker
    PVE (FW68D) / IDEMITSU
  • Oil Charge
    400cc
    Manufacturer / Country of Origin
    LG Electronics / China
FAN(INDOOR)
  • Type
    Cross Flow Fan
    Motor Output
    30W
FAN(OUTDOOR)
  • Type
    Propeller Fan
    Motor Type
    BLDC
  • Motor Output
    43W
    Motor Insulation
    Class E
  • Motor Enclosure / Ingress Protection
    TEAO/IPX4
HEAT EXCHANGER
  • Evaporator - Material, Tube / Fin
    Cu/Al
    Evaporator - (ø x Row x Column x FPI x L) x Qty.
    (ø7 x 2 x 16 x 20 x 744) x 1
  • Evaporator - Corrosion Protection
    PCM
    Evaporator - Fin Type
    Slit
  • Condenser - Material, Tube / Fin
    Cu/Al
    Condenser - (ø x Row x Column x FPI x L) x Qty.
    (ø7 x 2 x 24 x 18 x 823) x 1
  • Condenser - Corrosion Protection
    Gold
    Condenser - Fin Type
    Louver
